Product Detailed Parameters
- Description：RoHS, 4.20mmPitch Wafer, STR
- Series：4973
- Mfr：Oupiin
- Package：Bag
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.165" (4.20mm)
- Number of Positions：6
- Number of Rows：2
- Row Spacing - Mating：0.165" (4.20mm)
- Number of Positions Loaded：All
- Style：Board to Cable/Wire
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Locking Ramp
- Contact Length - Mating：-
- Contact Length - Post：0.134" (3.40mm)
- Overall Contact Length：-
- Insulation Height：0.504" (12.80mm)
- Contact Shape：Square
- Contact Finish - Mating：Tin
- Contact Finish Thickness - Mating：-
- Contact Finish - Post：Tin
- Contact Material：Brass
- Insulation Material：Polyamide (PA66), Nylon 6/6
- Features：-
- Operating Temperature：-40°C ~ 105°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-2
- Insulation Color：Natural
- Current Rating (Amps)：9A
- Voltage Rating：600VAC/DC
Download product information
Overview
The Oupiin 4973-06TSB is a coaxial/RF cable assembly component within the 4.2mm pitch connector series. It features a straight (STR) configuration and utilizes a wafer-style housing design. The product is identified as a male housing variant with six positions, intended for wire-to-board or cable interconnection applications requiring a 4.20mm spacing. This specific part number represents a finished assembly rather than a standalone housing.
Feature Summary
- Straight orientation configuration for direct board mounting
- Wafer-style housing design compatible with 4.2mm pitch systems
- Six-position layout for multi-signal interconnection
Applications
- General electronic interconnects
- Industrial equipment wiring
- Consumer electronics assemblies
Procurement Notes
Verify the exact specification against the manufacturer's current documentation, as the 4973 series includes various configurations such as male housings and different pin counts. Confirm whether the TSB suffix denotes a specific cable assembly type or a particular housing variant to ensure compatibility with the target PCB footprint and mating requirements.
Selection Notes
Select this component based on the requirement for a 4.20mm pitch connection in a straight form factor. Ensure the application supports the six-position capacity and that the mating interface aligns with the corresponding female contacts or cable ends specified in the full 4973 series datasheet.
Part Context
This component belongs to the Oupiin 4973 series, which covers 4.2mm pitch connectors including housings and terminals. The series is designed for general-purpose applications, offering options for single-row configurations and plastic polarizing features to ensure correct retention and mating alignment on printed circuit boards.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided documentation. Verify if other variants within the 4973 series, such as different pin counts or orientations, meet the functional requirements of the design.
