4976-1X03TD3T-M

Overview

The Oupiin 4976-1X03TD3T-M is a surface mount header connector from the 4976 series, designed for secure wire-to-board interconnections. It features a single row with three positions and a 3.0mm pitch. The housing is white, constructed to UL 94V-2 standards, and utilizes tin-plated terminals compatible with 22AWG to 28AWG wires. This component supports automated production via tape and reel packaging and offers robust contact locking mechanisms.

Feature Summary

• Surface mount design for automated PCB assembly
• Secure mating with locking features
• Compatible with wide AWG range

Applications

• Wire harness industry connections
• Automated electronic manufacturing
• Board-to-wire interconnects

Procurement Notes

Verify the specific suffix 'M' against the manufacturer's official datasheet to confirm terminal plating and orientation details. Ensure the tape and reel packaging specification matches the required automated placement equipment capabilities. Cross-reference the UL rating and current capacity with the system design requirements before finalizing the procurement order.

Selection Notes

Select this component when a low-profile, surface-mount solution is required for small gauge wires. The 3.0mm pitch provides adequate spacing for standard circuit layouts. Consider the tin plating for general purpose applications where gold is not strictly necessary. Verify that the 22AWG to 28AWG wire compatibility aligns with the harness specifications.

Part Context

This part belongs to the Oupiin 4976 series, which specializes in 3.0mm wire-to-board connectors. The series is characterized by secure mating, kinked leads for retention, and support for both straight and right-angle configurations. It is widely used in communication and industrial manufacturing sectors requiring reliable interconnects.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
