5-103634-8

Headers, Male Pins Overview

The 5-103634-8 is a rectangular connector header from the AMPMODU MTE series, manufactured by TE Connectivity AMP Connectors. It features a single row with nine positions and a 2.54mm (0.100 inch) pitch. The component utilizes through-hole right-angle termination for PCB mounting. Contacts are gold-plated brass with a mating surface thickness of 15.0µin (0.38µm). Rated current is 3A, operating temperature ranges from -65°C to 105°C, and insulation material is thermoplastic plastic.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting design for board-to-board or cable applications
• Gold-plated contacts ensure reliable electrical conductivity
• Thermoplastic housing provides thermal stability and UL94 V-0 flammability rating

Headers, Male Pins Applications

• Automotive electronics systems
• General purpose industrial equipment
• Medical device interconnections
• Telecommunications infrastructure

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required nine-position configuration and right-angle orientation. Confirm that the contact plating specifications meet the application's conductivity requirements. Ensure compatibility with standard 2.54mm pitch mating connectors. Check for any environmental certifications relevant to the deployment region.

Headers, Male Pins Selection Notes

Select this component when a right-angle, through-hole header is required for compact PCB layouts. The AMPMODU MTE series offers robust mechanical retention and high current capacity suitable for demanding environments. Consider the 3A rating and temperature range when evaluating thermal performance under load conditions.

Headers, Male Pins Part Context

This connector belongs to the AMPMODU MTE family, known for versatile interconnection solutions in automotive and industrial sectors. The series supports both crimp and IDC termination types across various pin counts. The 5-103634-8 variant specifically addresses needs for rigid board-to-board connections with precise alignment.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers: None identified.
