5003.0411.1

Overview

The Schurter 5003.0411.1 is a single-port power entry connector inlet designed for panel mounting applications. It features a current rating of 15A and operates at voltages up to 250V AC. The unit utilizes quick connect terminals with a 0.250 (6.3mm) pitch for circuit integration. This component belongs to the 5003 series and complies with RoHS environmental standards, ensuring suitability for modern electronic equipment requiring reliable power interface connections.

Feature Summary

• Single-port configuration for dedicated power input
• Quick connect termination method for simplified assembly
• RoHS compliant construction for environmental safety

Applications

• Industrial control panels
• Medical equipment power interfaces
• Consumer electronics enclosures

Procurement Notes

Verify that the specific terminal pitch matches the mating harness or PCB footprint requirements. Confirm voltage ratings align with the target system's electrical specifications. Ensure compliance with local regulatory standards for the intended market. Cross-reference the series designation to confirm accessory compatibility.

Selection Notes

Select this model when a single-phase power inlet with quick-connect capabilities is required. Consider the 15A current capacity against the load requirements. Evaluate the panel cutout dimensions to ensure proper mechanical fit. Verify insulation properties for the operating environment.

Part Context

This component is part of the Schurter 5003 series of power entry modules. These connectors are engineered for robust performance in various industrial and commercial settings. The series offers standardized dimensions and electrical characteristics to facilitate consistent design implementation across different product lines.
