5003.116B.1

Overview

The SCHURTER 5003.116B.1 is a single-phase EMI/RFI power line filter module designed for PCB mounting. It features a current rating of 3 A and operates at voltages up to 125 VAC. The unit utilizes PC pin termination for secure board integration. Physical dimensions are specified as 48.6 mm in width, 62 mm in depth, and 24.6 mm in height. This component provides electromagnetic interference suppression within a compact form factor suitable for space-constrained electronic assemblies.

Feature Summary

• Provides EMI and RFI suppression for single-phase AC power lines
• Integrates filtering functionality directly into the power entry module architecture
• Utilizes through-hole PC pin termination for standard PCB assembly processes

Applications

• Consumer electronics requiring mains power input filtering
• Industrial control systems needing EMI protection
• Medical equipment with strict electromagnetic compatibility requirements

Procurement Notes

Verify the specific voltage rating configuration against the target circuit design, as datasheets may list multiple voltage variants within the same series. Confirm that the PC pin spacing matches the printed circuit board layout exactly. Ensure the 3 A current rating exceeds the maximum operational load of the application to prevent thermal degradation or premature failure during continuous use.

Selection Notes

Select this component when a combined power inlet and EMI filter solution is required to minimize board space. The 3 A rating suits low-power applications, while the 125 VAC specification limits its use to lower voltage mains environments. Consider the physical footprint constraints, as the module measures 48.6 mm by 62 mm. Verify compliance with regional safety standards relevant to the final product deployment.

Part Context

This part belongs to Schurter's power entry connector portfolio, specifically the filtered module category. It combines electrical connectivity with noise suppression capabilities. The manufacturer specializes in components for industrial, medical, and consumer markets. This specific model represents a standardized solution for integrating basic EMI filtering without requiring separate discrete filter components on the main circuit board.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Evaluate alternative Schurter models within the same filtered power entry series based on matching current ratings and physical dimensions.
