Product Detailed Parameters
- Description：LINE FILTER 125VDC 10A PANEL MNT
- Series：5003
- Mfr：SCHURTER Inc.
- Package：Bulk
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：125V
- Voltage - Rated AC：-
- Current：10:00 AM
- Frequency - Operating：-
- Applications：Signal
- Approval Agency：cURus, ENEC, UL, VDE
- Operating Temperature：-25°C ~ 85°C
- Mounting Type：Panel Mount
- Termination Style：PC Pins
- Inductance：400µH
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The Schurter 5003.135B.1 is a single-phase EMI/RFI power line filter designed for DC applications. It features a rated voltage of 125VDC and a current capacity of 10A. The unit utilizes a rear panel mount configuration with solder terminals for PCB integration. This component provides single-stage filtering to suppress electromagnetic interference in signal and power lines, ensuring compliance with emission standards while maintaining low insertion loss.
Feature Summary
- Provides single-stage EMI/RFI suppression for DC power lines
- Designed for rear panel mounting with solder terminal connections
- Compatible with standard AC inlet panel cutouts for dual-purpose equipment design
Applications
- DC-powered industrial control systems
- Medical equipment requiring filtered DC input
- Telecommunications infrastructure
- Test and measurement instruments
Procurement Notes
Verify the specific datasheet version for the 5003.135B.1 to confirm current status, as some sources indicate it may be obsolete. Ensure compatibility with your system's 125VDC rating and 10A continuous current requirement. Confirm that the rear panel mount style and solder pin dimensions match your enclosure and PCB layout specifications before finalizing procurement.
Selection Notes
Select this component when a compact, single-stage filter is required for DC power inputs up to 125VDC. It is suitable for designs needing to share panel cutouts between AC and DC variants. Verify that the 10A current rating meets the load requirements and that the solder termination type aligns with the assembly process.
Part Context
This part belongs to Schurter's family of power entry modules and filters. It allows designers to create equipment compatible with both AC and DC power supplies by utilizing identical panel cutouts. The series focuses on providing essential EMI suppression in a compact form factor suitable for space-constrained electronic enclosures.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Consult Schurter technical support or updated distributor catalogs for equivalent single-stage DC filters with matching 125VDC and 10A ratings if this specific model is unavailable.
FAQ
Is the 5003.135B.1 suitable for AC applications?
No, this specific model is rated for 125VDC. While it shares panel cutouts with AC models, its internal filtering characteristics are optimized for DC lines.
What is the mounting style for this filter?
The 5003.135B.1 uses a rear panel mount style with solder terminals for connection to the printed circuit board.
