Product Detailed Parameters
- Description：LINE FILTER 125VDC 10A PANEL MNT
- Series：5003
- Mfr：SCHURTER Inc.
- Package：Bulk
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：125V
- Voltage - Rated AC：-
- Current：10:00 AM
- Frequency - Operating：-
- Applications：Signal
- Approval Agency：cURus, ENEC, UL, VDE
- Operating Temperature：-25°C ~ 85°C
- Mounting Type：Panel Mount
- Termination Style：PC Pins
- Inductance：400µH
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The SCHURTER 5003.136B.1 is a single-phase EMC/EMI line filter module designed for power entry applications. It supports a rated current of 10 A and operates at voltages up to 125 VAC. The unit features PC pin termination for printed circuit board mounting. This component integrates shielding to mitigate electromagnetic interference, ensuring compliance with environmental standards such as ECO Design.
Feature Summary
- Integrates single-stage EMI filtering within a compact power entry module
- Includes internal shielding to enhance electromagnetic compatibility performance
- Designed for direct PCB mounting via PC pin terminals
Applications
- Consumer electronics power supplies
- Appliance input stages
- Industrial equipment power interfaces
Procurement Notes
Verify the specific voltage rating and current capacity against the target circuit requirements before integration. Confirm that the PC pin pitch matches the printed circuit board layout. Ensure the shielding configuration aligns with the enclosure design to maintain effective EMI suppression. Check for any regional regulatory certifications required for the end product.
Selection Notes
Select this component when space constraints require an integrated filter solution rather than discrete components. It is suitable for applications needing standard single-phase protection without complex multi-stage filtering. Consider the thermal environment and mounting orientation to ensure reliable operation within the specified temperature range.
Part Context
This part belongs to the SCHURTER 5003 Series of power entry connectors. The series combines inlet functionality with filtering capabilities in a unified module. These components are engineered for reliability in consumer and industrial electronic devices requiring clean power input.
FAQ
What type of termination does the 5003.136B.1 use?
It uses PC pins for through-hole printed circuit board mounting.
Is the 5003.136B.1 shielded?
Yes, the datasheet specifies that the unit includes shielding for enhanced EMI performance.
