5003.2211.1

$13.04

Description：LINE FILTER 125VDC PANEL MOUNT
Series：5003
Mfr：SCHURTER Inc.
Package：Bulk

SKU:ee2c4d8812fa Category: Power Line Filter Modules Brand: SCHURTER Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LINE FILTER 125VDC PANEL MOUNT
Series：5003
Mfr：SCHURTER Inc.
Package：Bulk
Filter Type：Single Phase
Configuration：Single Stage
Voltage - Rated DC：125V
Voltage - Rated AC：-
Current：-
Frequency - Operating：-
Applications：Signal
Approval Agency：cURus, ENEC, UL, VDE
Operating Temperature：-25°C ~ 85°C
Mounting Type：Panel Mount
Termination Style：-
Inductance：-
Voltage - Rated AC (Phase to Ground/Neutral)：-
Voltage - Rated AC (Phase to Phase)：-

Download product information

5003.2211.1

Overview

The Schurter 5003.2211.1 is a single-phase EMC/EMI line filter module designed for power line noise suppression. It operates at a rated voltage of 125V AC and supports a maximum current of 10A. The component utilizes a single-stage filtering architecture to attenuate electromagnetic interference in AC power circuits. It features quick-connect terminals for PCB integration and is housed in a thermoplastic enclosure compliant with UL 94 V-0 flammability standards. The unit is engineered for panel mounting applications within compact electronic assemblies requiring reliable EMI reduction.
