5003.2411.1

Overview

The SCHURTER 5003.2411.1 is a single-phase AC power entry module designed for integration into electronic equipment requiring electromagnetic compatibility filtering. This unit features an integrated EMC/EMI line filter and supports a maximum current rating of 15 A at 125 V AC. It utilizes a DC connector interface configuration, specifically compatible with C18 inlet and C14 plug standards. The device operates within a temperature range of -25°C to +85°C and incorporates a 5 x 20 mm fuse holder for circuit protection. The module employs quick-connect terminals for PCB mounting.

Feature Summary

• Integrated single-stage EMC/EMI line filter for noise suppression
• Supports high-current operation up to 15 A
• Includes built-in fuse holder for 5 x 20 mm fuses
• Utilizes quick-connect terminal interface for board mounting

Applications

• Medical equipment power supplies
• Industrial control systems
• Audio-visual electronics

Procurement Notes

Verify the specific voltage rating requirements against the datasheet, as this model is specified for 125 V AC operation. Confirm that the 15 A current capacity aligns with the system's load demands. Ensure the quick-connect terminal pitch matches the target PCB layout. Check for any regional certification requirements such as UL or VDE if applicable to the final assembly.

Selection Notes

Select this component when a compact solution combining power entry, filtering, and overcurrent protection is required. It is suitable for applications where space constraints prevent separate filter installation. Consider the 125 V AC limitation when designing for global markets; higher voltage variants may be necessary for 230 V regions. Evaluate thermal management needs given the 15 A rating and enclosed filter design.

Part Context

This part belongs to Schurter's 5003 series of power entry modules. These modules are engineered to provide reliable power connection while mitigating electromagnetic interference. The series typically offers various current ratings and filter configurations to suit different regulatory and performance standards in consumer and industrial electronics.

Replacement Considerations

Cross-reference with other Schurter 5003 series models for alternative current ratings or voltage specifications. Verify pinout compatibility before substituting with generic equivalents. Ensure any replacement maintains the same IP rating and thermal characteristics.
