Product Detailed Parameters
- Description：LINE FILTER 520VAC 50A CHASS MNT
- Series：KES
- Mfr：TE Connectivity Corcom Filters
- Package：Box
- Filter Type：Three Phase (Delta)
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：520V
- Current：50 A
- Frequency - Operating：50 ~ 60Hz
- Applications：General Purpose
- Approval Agency：CSA, UL
- Operating Temperature：-25°C ~ 85°C
- Mounting Type：Chassis Mount
- Termination Style：Threaded Post (M6)
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The 50KEBS6BFPDVM is a single-phase power line filter from the KEB series by TE Connectivity Corcom. It features a nut delta mounting configuration and is rated for 50A current at 440VAC with a 50Hz operating frequency. The component provides EMI/RFI filtering for industrial applications requiring robust noise suppression in high-current AC power circuits.
Feature Summary
- Provides electromagnetic interference and radio frequency interference suppression
- Designed for single-phase AC power line applications
- Utilizes a nut delta mechanical mounting configuration
Applications
- Industrial machinery power input stages
- High-current AC power distribution systems
- Equipment requiring EMI/RFI noise reduction in 440VAC environments
Procurement Notes
Verify the exact suffix designation against the manufacturer's official documentation to confirm specific terminal or housing variations. Confirm availability status as product lifecycles may change. Ensure the 50A rating and 440VAC voltage align with the system requirements before procurement.
Selection Notes
Select this component when a 50A single-phase filter is required for 440VAC systems. The nut delta mounting style dictates the panel integration method. Verify that the 50Hz frequency specification matches the local power grid standards. Ensure the enclosure allows for the specified physical dimensions of the KEB series unit.
Part Context
This part belongs to the KEB series of power line filters manufactured by TE Connectivity Corcom. The series is engineered for demanding industrial environments, offering high current handling capabilities. The specific model integrates filtering components within a chassis-mountable housing designed for secure installation via nut delta fastening.
Replacement Considerations
Consult the official TE Connectivity Corcom selector charts for direct replacements. Verify that any substitute maintains the 50A current rating, 440VAC voltage rating, and single-phase configuration. Mechanical compatibility with the nut delta mounting interface must be confirmed.
