50KEPS10BFPW

Overview

The 50KEPS10BFPW is a three-phase power line filter manufactured by TE Connectivity / Corcom. It features a single-stage design rated for 50 A current and 520 VAC voltage. The unit supports 50 Hz and 60 Hz operating frequencies with a leakage current of 8.5 mA. Physical dimensions are 202 mm in length, 135 mm in width, and 80 mm in height. It utilizes terminal block connections and chassis mounting. Compliance includes UL and CSA certifications.

Feature Summary

• Single-stage EMI mitigation for three-phase systems
• Terminal block interface for secure electrical connection
• Chassis mount configuration for industrial integration

Applications

• Industrial automation equipment
• Power distribution systems
• Electromagnetic compatibility compliance

Procurement Notes

Verify component authenticity through authorized channels due to lifecycle status. Confirm technical specifications against original datasheets as the product may be obsolete. Ensure replacement parts meet identical electrical ratings and physical constraints for system compatibility.

Selection Notes

Select this model for applications requiring 50 A capacity at 520 VAC. Verify terminal block compatibility with existing wiring infrastructure. Consider chassis mounting requirements and thermal limits within the specified -25 C to +85 C range during system design.

Part Context

This component belongs to the KEP series of power line filters from TE Connectivity / Corcom. The series provides electromagnetic interference filtering for three-phase power lines. The specific model addresses high-current industrial needs with standardized mounting and connection interfaces.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
