Overview

The SICK WTB2SC-2P3244A00 is a background suppression photoelectric sensor from the W2S-2 series. It features a block-style housing with a red light source and IO-Link interface. The device provides PNP output via a 4-pin connector or screw terminals. It operates on a maximum DC voltage of 30V with a current consumption of 50mA. The detection range spans from 4 mm to 110 mm, with a response time of 500μs. It offers IP67 protection and functions between -25°C and 50°C.

Feature Summary

• Background suppression technology for consistent object detection regardless of surface reflectivity
• IO-Link interface enabling digital communication and parameterization
• Dual connection options including 4-pin connector and screw terminals

Applications

• Automated assembly line monitoring
• Packaging machine object presence verification
• Conveyor belt item detection in logistics systems

Procurement Notes

Verify the specific ordering suffix against the manufacturer datasheet to confirm electrical characteristics and cable length requirements. Ensure the application environment temperature remains within the specified operational limits. Confirm that the control system logic aligns with the PNP switching output configuration before deployment.

Selection Notes

Select this model when precise distance-dependent detection is required without sensitivity to target color or material properties. The IO-Link capability supports advanced diagnostics and configuration management. Consider the compact block design for installations with limited spatial constraints.

Part Context

This component belongs to the W2S-2 series of photoelectric sensors designed for industrial automation. The series emphasizes reliability and ease of integration through standardized interfaces. Background suppression variants are optimized for applications where target reflectivity varies significantly.

FAQ

What is the primary detection principle used by this sensor?

It utilizes background suppression technology to detect objects based on distance rather than signal intensity.

Does this sensor support digital communication protocols?

Yes, it includes an IO-Link interface for digital data exchange and parameter setting.
