5500.2029

Overview

The Schurter 5500.2029 is a single-stage power line filter module designed for AC mains applications. It supports rated voltages of 125 VAC and 250 VAC with a continuous current rating of 6 A at operating frequencies of 50 Hz and 60 Hz. The component utilizes quick connect terminals for circuit integration and is engineered for chassis mounting. It operates within a temperature range of -25°C to +100°C and maintains leakage current within specified safety limits.

Feature Summary

• Single-stage EMI/EMI filtering topology
• Chassis mount mechanical design
• Quick connect terminal interface

Applications

• Industrial equipment power conditioning
• Medical device input stages
• Office automation hardware

Procurement Notes

Verify the specific datasheet version to confirm exact attenuation curves and physical dimensions. Ensure the application voltage does not exceed the 250 VAC rating. Confirm that the quick connect terminal type matches the mating connector specifications in the system design.

Selection Notes

Select this component when a single-stage filter solution is sufficient for the required noise suppression levels. The 6 A rating suits moderate power loads. Verify that the chassis mounting style fits the enclosure constraints and that the quick connect termination method aligns with the PCB or wire harness design.

Part Context

This part belongs to the Schurter 5500 series, which encompasses various power line filter modules. The series offers different stage configurations and current ratings to address diverse electromagnetic compatibility requirements across industrial and commercial electronic equipment sectors.

Replacement Considerations

Consult official Schurter documentation for verified substitute part numbers. Cross-referencing requires matching electrical ratings, mounting styles, and terminal types to ensure functional equivalence.
