5500.2059

Overview

The Schurter 5500.2059 is a single-phase power line filter designed for electromagnetic interference suppression in electrical circuits. It features a chassis mount configuration with quick connect terminals for straightforward integration. The component operates at a rated voltage of 125VAC and 250VAC, supporting a current rating of 3A. It functions effectively at operating frequencies of 50Hz and 60Hz. The unit provides an inductance value of 2mH and maintains an operational temperature range from -25°C to 100°C.

Feature Summary

• Single-stage filtering architecture for effective noise reduction
• Chassis mounting style ensures secure physical installation
• Quick connect terminal type facilitates rapid circuit integration

Applications

• Industrial equipment power conditioning
• Electromagnetic compatibility enhancement in electronic assemblies
• Power line noise suppression applications

Procurement Notes

Verify the specific datasheet version to confirm compliance with current safety standards such as UL, CSA, VDE, or EN, as certification status may vary by production batch. Ensure that the quick connect terminal dimensions match the target PCB or wiring harness specifications. Confirm the thermal derating curves align with the intended ambient temperature conditions within the final enclosure design to prevent performance degradation.

Selection Notes

Select this model when a single-stage solution is sufficient for the required attenuation levels. The 3A current rating suits moderate load applications. Verify that the 2mH inductance meets the impedance requirements of the specific circuit. Consider the chassis mount requirement against available panel space. Compare against higher-current or multi-stage alternatives if stricter EMI regulations apply to the end product.

Part Context

This component belongs to the Schurter power line filter portfolio, which specializes in EMC/EMI solutions. The 5500 series typically includes various configurations tailored for different current ratings and mounting styles. This specific part represents a standard industrial-grade filter option focusing on reliability and ease of installation for general-purpose power line protection.

Replacement Considerations

Direct substitutes include other Schurter models within the same series offering identical 3A ratings and chassis mount formats. Cross-reference terminal types and inductance values to ensure functional equivalence. Verify that alternative parts meet the same voltage and temperature specifications.
