5500.2078

Overview

The Schurter 5500.2078 is a single-phase, single-stage power line filter designed for chassis mounting. It operates at rated voltages of 125 VAC and 250 VAC with a current rating of 2 A. The component features an inductance of 4 mH and utilizes quick connect terminals for circuit integration. Certified under UL standards, it functions at 50 Hz and 60 Hz frequencies.

Feature Summary

• Single-stage EMI/EMI filtering configuration
• Cost-optimized design for medical applications
• Chassis mount installation style

Applications

• Medical equipment power conditioning

Procurement Notes

Verify the specific ordering suffix to confirm terminal type and voltage ratings. Confirm RoHS compliance status through official documentation. Check lead times as availability varies by region. Ensure the selected variant matches the required chassis mounting dimensions and electrical specifications for the target application.

Selection Notes

Select this model for applications requiring low-cost, single-stage filtration. The 2 A rating suits light-load medical devices. Verify that the quick connect interface aligns with the PCB or wiring harness design. Consider leakage current limits if patient safety isolation is critical.

Part Context

This component belongs to the Schurter 5500 series of AC line filters. It is part of a family offering various current ratings and stage configurations. The 5500.2078 specifically targets cost-sensitive markets while maintaining essential EMC performance standards for regulated industries.

Replacement Considerations

No public confirmed substitute part numbers are available.
