Product Detailed Parameters
- Description：LINE FILTER 125V/250VAC 4A CHASS
- Series：FMLB-41
- Mfr：SCHURTER Inc.
- Package：Bulk
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：125V, 250V
- Current：4:00 AM
- Frequency - Operating：50/60Hz
- Applications：Medical
- Approval Agency：cURus, ENEC, VDE
- Operating Temperature：-25°C ~ 100°C
- Mounting Type：Chassis Mount
- Termination Style：Quick Connect
- Inductance：1.5mH
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The SCHURTER 5500.2079 is a single-phase, single-stage EMI/EMI line filter module designed for power line conditioning. It features a rated current of 4 A and operates at voltages up to 250 VAC with frequencies of 50 Hz or 60 Hz. The unit incorporates an inductance value of 1.5 mH to suppress electromagnetic interference. Termination is achieved via quick connect terminals, facilitating integration into various electrical assemblies.
Feature Summary
- Single-stage filtering architecture for effective noise suppression
- Compact modular design suitable for space-constrained installations
- Quick connect terminal configuration for simplified wiring
Applications
- Industrial control systems requiring EMI suppression
- Medical equipment power input stages
- Consumer electronics power supplies
Procurement Notes
Verify the specific datasheet version for the 5500.2079 to confirm exact leakage current limits and insertion loss characteristics. Ensure that the quick connect terminal dimensions match the mating connector specifications in your assembly design. Cross-reference compliance certifications such as UL, CSA, VDE, and EN against regional regulatory requirements before finalizing procurement decisions.
Selection Notes
Select this component when a single-stage solution is sufficient for the required attenuation levels. The 4 A rating defines the maximum continuous load capacity. Verify that the 1.5 mH inductance provides adequate impedance for the target noise spectrum. Consider the physical footprint and terminal type compatibility during the initial circuit board or chassis layout phase.
Part Context
This component belongs to the FMLB-41 series from Schurter, which focuses on compact power line filters. The series offers various current ratings and termination options. The 5500.2079 specifically addresses applications needing moderate current handling with straightforward installation methods.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Consult Schurter technical support for direct equivalents within the FMLB-41 series or other compatible product lines.
