Product Detailed Parameters
- Description：LINE FILTER 125V/250VAC 10A CHAS
- Series：FMLB-41
- Mfr：SCHURTER Inc.
- Package：Bulk
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：125V, 250V
- Current：10:00 AM
- Frequency - Operating：50/60Hz
- Applications：Medical
- Approval Agency：cURus, ENEC, VDE
- Operating Temperature：-25°C ~ 100°C
- Mounting Type：Chassis Mount
- Termination Style：Quick Connect
- Inductance：300µH
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The Schurter 5500.2081 is a single-phase AC power line filter belonging to the FMLB-41 series. It features a linear filter topology designed for chassis or panel mounting applications. The component supports a rated current of 10A and operates at voltages up to 250V AC with a frequency of 60Hz. Electrical termination is provided via quick-connect terminals, while mechanical fixation utilizes screw mounting terminals. The unit functions within an operating temperature range from -25°C to 100°C.
Feature Summary
- Linear EMI suppression topology for noise reduction
- Quick-connect electrical interface for circuit integration
- Screw terminal mounting for secure chassis installation
Applications
- Industrial equipment power input stages
- Medical device power supply filtering
- Office automation hardware protection
Procurement Notes
Verify the specific datasheet version for the 5500.2081 part number to confirm exact compliance certifications such as UL, CSA, VDE, or EN. Ensure that the required leakage current limits and insertion loss characteristics align with the target system's electromagnetic compatibility requirements before finalizing procurement decisions.
Selection Notes
Select this model when a 10A capacity is required for 250V AC systems utilizing quick-connect wiring. The FMLB-41 series offers a compact form factor suitable for space-constrained enclosures. Confirm that the operating temperature range of -25°C to 100°C meets the environmental conditions of the intended deployment site.
Part Context
This component is part of Schurter's FMLB-41 series of IEC filters. The series provides various current ratings and mounting options for general-purpose EMI suppression. The 5500.2081 specifically addresses applications requiring robust linear filtering with standard quick-connect interfaces for reliable power line conditioning.
Replacement Considerations
Cross-reference with other FMLB-41 variants for different current ratings. Verify pinout compatibility if substituting with similar linear filters from alternative manufacturers.
