5500.2086

Overview

The SCHURTER 5500.2086 is a single-phase, single-stage power line filter designed for chassis mounting. It operates at rated voltages of 125 VAC and 250 VAC with a current rating of 6 A. The component utilizes quick connect terminals for circuit integration and functions at standard frequencies of 50 Hz and 60 Hz. It carries UL compliance certification.

Feature Summary

• Single-stage electromagnetic interference suppression
• Chassis mount mechanical configuration
• Quick connect terminal interface

Applications

• Industrial equipment power conditioning
• Medical device power supply filtering
• Consumer electronics EMI reduction

Procurement Notes

Verify the specific datasheet version to confirm exact leakage current values and inductance ratings, as distributor summaries may vary. Ensure the quick connect terminal dimensions match the target PCB or wire harness specifications. Confirm that the chassis mounting hole pattern aligns with the enclosure design requirements before finalizing procurement.

Selection Notes

Select this model for applications requiring moderate attenuation in single-phase AC circuits. The 6 A rating suits low-to-medium power loads. Verify that the 125/250 VAC rating matches the local mains voltage. Consider the chassis mount style if panel installation is preferred over PCB mounting.

Part Context

This component belongs to the FMLB series of power line filters from SCHURTER. The series offers various current ratings and stage configurations. The 5500.2086 specifically addresses single-stage filtering needs for 6 A applications, providing a compact solution for basic EMI suppression tasks in regulated environments.

Replacement Considerations

Cross-reference with other SCHURTER FMLB series parts for different current ratings. Verify compatibility with equivalent single-stage filters from other manufacturers by comparing inductance, voltage, and current specifications.
