Product Detailed Parameters
- Description：LINE FILTER 125V/250VAC 1A CHASS
- Series：FMLB-41
- Mfr：SCHURTER Inc.
- Package：Bulk
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：125V, 250V
- Current：1:00 AM
- Frequency - Operating：50/60Hz
- Applications：Medical
- Approval Agency：cURus, ENEC, VDE
- Operating Temperature：-25°C ~ 100°C
- Mounting Type：Chassis Mount
- Termination Style：Quick Connect
- Inductance：10mH
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The Schurter 5500.2089 is a single-phase, single-stage EMC/EMI power line filter designed for chassis mounting. It supports a rated current of 1 A and operates at voltage ratings of 125 VAC and 250 VAC with a frequency range of 50 Hz to 60 Hz. The component utilizes quick connect termination types and complies with UL standards. This filter serves as a medical version variant within the product series.
Feature Summary
- Single-stage EMI/EMC filtering capability for single-phase applications
- Chassis mount construction with quick connect termination
- Medical version classification ensuring specific safety compliance
Applications
- Medical equipment power supply input protection
- Industrial control systems requiring single-stage filtration
- Electronic devices needing 1 A line noise suppression
Procurement Notes
Verify the specific UL file number and medical certification details against the official datasheet before integration. Confirm that the quick connect terminal specifications match the target PCB or wire harness requirements. Ensure the chassis mounting dimensions align with the enclosure design constraints.
Selection Notes
Select this component when single-stage attenuation is sufficient for the application's EMI profile. The 1 A rating limits suitability to low-power circuits. Verify that the quick connect interface is compatible with existing assembly processes. Consider the medical version designation if regulatory compliance for healthcare environments is required.
Part Context
This part belongs to the Schurter 5500 series of power line filters. It represents a specialized medical variant within the broader lineup of single-phase EMI filters. The series offers various current ratings and stage configurations to address different noise suppression needs across industrial and consumer electronics sectors.
Replacement Considerations
Consult the official Schurter replacement guide for verified substitutes. Cross-reference electrical ratings and mechanical dimensions to ensure compatibility.
