Product Detailed Parameters
- Description：LINE FILTER 125V/250VAC 6A CHASS
- Series：FMLB-41
- Mfr：SCHURTER Inc.
- Package：Bulk
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：125V, 250V
- Current：6:00 AM
- Frequency - Operating：50/60Hz
- Applications：Medical
- Approval Agency：cURus, ENEC, VDE
- Operating Temperature：-25°C ~ 100°C
- Mounting Type：Chassis Mount
- Termination Style：Quick Connect
- Inductance：800µH
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The Schurter 5500.2092 is a single-phase power line filter module designed for chassis mounting. It operates at rated voltages of 125 VAC and 250 VAC with a current rating of 6 A. The unit utilizes quick connect terminals for circuit integration. Key electrical specifications include an inductance of 14 mH and a maximum leakage current of 350 uA. It functions within a frequency range of 50 Hz to 60 Hz. The component complies with UL, CSA, VDE, and EN safety standards.
Feature Summary
- Single-stage EMI filtering architecture
- Chassis mount mechanical design
- Quick connect terminal interface
Applications
- Industrial equipment power conditioning
- Medical device power supply input
- Commercial appliance noise suppression
Procurement Notes
Verify the specific datasheet version for the 5500.2092 model to confirm exact leakage current limits and compliance certifications. Ensure the application voltage matches the 125/250 VAC rating. Confirm that the quick connect terminal type aligns with the system wiring harness requirements before finalizing procurement.
Selection Notes
Select this component when a compact, single-phase filter is required for chassis installation. It is suitable for applications needing 6 A capacity with standard quick connect termination. Consider the 14 mH inductance value for expected attenuation performance. Verify space constraints accommodate the physical dimensions of the FMLB series module.
Part Context
This part belongs to the Schurter FMLB series of power line filters. The series provides single-stage filtering solutions for various industrial and commercial applications. The FMLB modules are characterized by their robust construction and standardized terminal configurations, facilitating easy integration into existing power distribution systems.
Replacement Considerations
Cross-reference with other FMLB series variants for different current ratings or terminal styles. Verify compatibility with equivalent single-stage filters from other manufacturers based on inductance and voltage ratings.
