5500.2121

Overview

The SCHURTER 5500.2121 is a single-stage power line filter designed for AC mains applications. It supports voltage ratings of 125 VAC and 250 VAC with a current rating of 700 mA. The component utilizes through-hole mounting and operates at standard frequencies of 50 Hz and 60 Hz. It belongs to the FPP series, offering compact EMI suppression for low-current circuits.

Feature Summary

• Single-stage EMI filtering architecture
• Through-hole terminal configuration
• Dual voltage compatibility

Applications

• Low-power electronic equipment
• Medical devices
• Industrial control systems

Procurement Notes

Verify the specific datasheet revision when sourcing, as manufacturer documentation may vary across regions. Confirm that the 700 mA rating aligns with your circuit requirements. Ensure compliance with local safety standards such as UL or IEC before final integration into regulated products.

Selection Notes

Select this model for applications requiring basic noise attenuation in space-constrained designs. It serves as an alternative to higher-capacity filters when current demands remain below one ampere. Evaluate leakage current specifications against sensitive input requirements.

Part Context

This component is part of Schurter's general-purpose line filter portfolio. It complements other FMLB and FMW series units by providing a specialized option for lower current loads. The product focuses on essential interference reduction without complex multi-stage topologies.

Replacement Considerations

Consult official substitution guides for direct equivalents. Verify pinout compatibility and thermal characteristics before swapping with similar single-stage filters from other manufacturers.
