5500.2128

Overview

The Schurter 5500.2128 is a single-phase, single-stage EMI power line filter designed for PCB mounting. It supports voltage ratings of 125 VAC and 250 VAC with a current rating of 6.5 A. The component utilizes M5 screw terminals for secure connection and operates at standard frequencies of 50 Hz and 60 Hz. This filter provides electromagnetic interference suppression for electronic equipment requiring reliable power line conditioning.

Feature Summary

• Single-stage filtering architecture for effective noise attenuation
• PCB mount configuration with M5 terminal connections
• Dual voltage rating capability for global compatibility

Applications

• Industrial control systems
• Medical equipment power supplies
• Consumer electronics AC input stages

Procurement Notes

Verify the specific datasheet version to confirm exact leakage current and insertion loss characteristics. Ensure mechanical clearance accommodates the M5 terminal spacing. Confirm RoHS compliance status matches project requirements before finalizing procurement orders.

Selection Notes

Select this model when a compact, single-stage solution is required for 6.5 A applications. Compare against higher-current FMLB series options if load demands exceed rated capacity. Verify chassis or panel space constraints align with the PCB footprint dimensions.

Part Context

This component belongs to the Schurter 5500 series of power line filters. The series offers various configurations including FMLB and FPP types. The 5500.2128 specifically addresses needs for moderate current filtering with direct PCB integration capabilities.

Replacement Considerations

Check Schurter documentation for cross-reference models within the 5500 series. Verify pinout compatibility and thermal performance before substituting with other manufacturers' components.
