5500.223

Overview

The Schurter 5500.223 is a single-phase, two-stage power line filter designed for chassis mounting with screw terminals. It supports voltage ratings of 125 VAC and 250 VAC at a current rating of 6 A. The component operates at frequencies of 50 Hz and 60 Hz, featuring a leakage current of 250 uA and an inductance of 800 uH. Certified by UL, CSA, VDE, and EN standards, it belongs to the FMW2 series.

Feature Summary

• Two-stage filtering architecture for enhanced noise suppression
• Chassis mount design with screw terminal connections
• Compliant with international safety certifications including UL, CSA, VDE, and EN

Applications

• Industrial equipment requiring EMI/RFI suppression
• Medical devices needing certified power conditioning
• Electronic systems operating on 125VAC or 250VAC mains

Procurement Notes

Verify the exact suffix against official datasheets, as variations like 5500.2230 exist. Confirm terminal type and current ratings match system requirements. Check certification marks (UL, CSA, VDE) for specific regional compliance needs before procurement.

Selection Notes

Select this model for applications requiring robust two-stage filtration in a compact chassis-mount form factor. Ensure the 6A current rating and 800 uH inductance align with load specifications. Verify that screw terminals are compatible with the assembly process compared to quick-connect alternatives.

Part Context

This component is part of Schurter's FMW2 series of power line filters. It serves as a specialized solution for electromagnetic interference mitigation in AC power circuits, distinct from single-stage variants or DC-specific filters within the broader product portfolio.

Replacement Considerations

The 5500.2230 is a documented variant within the same series. Verify if the specific suffix indicates differences in packaging or minor electrical tolerances before substitution.
