5500.2232

Overview

The Schurter 5500.2232 is a single-phase power line filter designed for chassis mounting. It features a voltage rating of 80 VDC and a current rating of 20 A. The component operates within a temperature range of -25 to 100 °C. It complies with UL, CSA, VDE, and EN standards.

Feature Summary

• Provides EMI/EMC filtering for DC power lines
• Designed for secure chassis mounting installation

Applications

• Industrial equipment power conditioning
• DC power supply input protection
• Electronics requiring EMC compliance

Procurement Notes

Verify the specific datasheet version (e.g., 5500.2232(1).pdf or 5500.2232(2).pdf) as multiple documents exist. Confirm that the 80 VDC rating aligns with your system requirements, as other models in this series may support higher AC voltages. Ensure chassis mounting hardware compatibility before procurement.

Selection Notes

Select this model specifically for low-voltage DC applications requiring 20 A capacity. Verify that the 80 VDC maximum rating exceeds your circuit's operating voltage. Consider the chassis mount style and terminal configuration during PCB or panel layout planning to ensure proper physical integration.

Part Context

This component belongs to the Schurter 5500 series of power line filters. It is categorized under EMI/EMC filters and power conditioners. The series includes various ratings for different voltage and current requirements across AC and DC applications.

Replacement Considerations

No public substitute part numbers are confirmed in the provided documentation.
