- Description：LINE FILTER 125V/250VAC 1A CHASS
- Series：FMAB NEO
- Mfr：SCHURTER Inc.
- Package：Box
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：125V, 250V
- Current：1:00 AM
- Frequency - Operating：50/60Hz
- Applications：Medical
- Approval Agency：cURus, ENEC, VDE
- Operating Temperature：-40°C ~ 100°C
- Mounting Type：Chassis Mount
- Termination Style：Quick Connect
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The SCHURTER Inc. 5500.2630.07 is a single-phase EMC/EMI line filter designed for chassis mounting. It features quick connect termination style and operates within a temperature range of -40°C to 100°C. The component supports 125VAC and 250VAC ratings at 50/60Hz with a current capacity of 1A. It provides high symmetrical attenuation in a single-stage configuration.
Feature Summary
- Provides high symmetrical attenuation for effective noise suppression
- Designed as a single-stage EMC/EMI line filter solution
- Utilizes quick connect termination for simplified circuit integration
Applications
- Single-phase power supply input filtering
- Electronic equipment requiring EMI suppression
- Chassis-mounted AC line conditioning
Procurement Notes
Verify the specific voltage rating (125VAC or 250VAC) required for your application against the datasheet specifications. Confirm that the quick connect termination style matches your PCB or wire harness design. Ensure the operating temperature range of -40°C to 100°C meets your environmental requirements before finalizing procurement.
Selection Notes
Select this component when a single-stage, single-phase filter is sufficient for your noise reduction needs. Consider the 1A current rating and chassis mount form factor. Verify compatibility with your system's voltage standards (125VAC/250VAC) and ensure adequate space for chassis installation.
Part Context
This part belongs to the SCHURTER 5500 series of power line filters. These components are engineered for electromagnetic interference suppression in AC power lines. The series offers various configurations for different current and voltage applications, focusing on reliable noise attenuation in compact chassis-mount packages.
Replacement Considerations
Check for direct substitutes within the 5500 series with matching current and voltage ratings. Ensure any replacement maintains the same quick connect termination style and chassis mount dimensions. Verify equivalent attenuation characteristics to maintain system compliance.
