5500.2633.01

Overview

The SCHURTER Inc. 5500.2633.01 is a single-phase EMC/EMI power line filter from the FMAB NEO series, rated for 6 A at 250 VAC and 125 VAC. Designed for flange mounting with quick connect terminals, it operates within a temperature range of -40°C to 100°C. The unit features cULus certification and complies with RoHS3 standards. It provides single-stage filtering for 50/60 Hz applications, ensuring effective noise suppression in AC and DC power systems while maintaining low resistance and power loss characteristics.

Feature Summary

• Single-stage electromagnetic interference (EMI) and radio frequency interference (RFI) filtering
• Flange mount design with quick connect termination style
• Medical grade compliance suitable for sensitive equipment
• RoHS3 compliant construction

Applications

• Medical equipment power supplies
• Industrial control systems
• LED drivers and ballasts
• Battery-operated systems

Procurement Notes

Verify the specific voltage rating (125V or 250V) required for your application against the datasheet specifications. Confirm that the quick connect terminal type matches your PCB or wiring harness interface. Ensure the flange mounting dimensions are compatible with your enclosure design. Check for current derating requirements if operating near the maximum 6A limit or at elevated temperatures above standard ratings.

Selection Notes

Select this component when single-phase EMI suppression is needed for devices drawing up to 6A. The FMAB NEO series offers a compact form factor suitable for space-constrained enclosures. Consider the operating temperature range of -40°C to 100°C for environmental suitability. The quick connect termination simplifies assembly compared to solder-only options. Verify insulation and leakage current specifications if used in medical or safety-critical applications.

Part Context

This part belongs to Schurter's FMAB NEO series of single-phase power line filters. These filters are engineered for general industrial and commercial use, providing reliable noise attenuation. The series is known for its robust construction and compliance with international safety standards. It serves as a critical component for meeting EMC directives in electronic devices requiring clean power input.

Replacement Considerations

Direct substitutes include other Schurter FMAB NEO models with similar current ratings, such as 5500.2652.01, though terminal types and exact dimensions may vary. Cross-brand replacements require matching voltage, current, and mounting constraints. Verify that any alternative meets the same cULus certification and RoHS3 compliance requirements.
