5500.2633.07

Overview

The SCHURTER Inc. 5500.2633.07 is a single-phase EMC/EMI line filter module designed for chassis mounting. It operates at rated voltages of 125VAC and 250VAC with a current rating of 6A at 50/60Hz. The component utilizes a single-stage filtering architecture and features quick-connect terminals for circuit integration.

Feature Summary

• Single-phase electromagnetic compatibility (EMC) and electromagnetic interference (EMI) filtering
• Chassis-mountable design for industrial equipment integration
• Quick-connect terminal configuration for simplified wiring

Applications

• Industrial power supply units
• Medical electronic equipment
• Computer equipment power inputs

Procurement Notes

Verify the specific datasheet version to confirm exact attenuation curves and leakage current specifications required for your application. Ensure the chassis mounting dimensions align with your enclosure design. Confirm that the quick-connect terminal spacing matches your PCB or wire harness layout before finalizing procurement.

Selection Notes

Select this component when single-stage EMI suppression is sufficient for the noise environment. The 6A rating suits moderate power applications. Verify compliance requirements such as RoHS status against project specifications. Consider thermal derating if operating near the maximum current limit in enclosed spaces.

Part Context

This part belongs to Schurter's power line filter modules category, which provides passive filtering solutions for AC mains inputs. These components are engineered to reduce conducted emissions from switching power supplies and protect downstream circuits from external electrical noise.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Consult official Schurter resources for equivalent series alternatives.
