5500.2635.04

Overview

The SCHURTER Inc. model 5500.2635.04 is a single-phase, single-stage power line filter designed for chassis mounting. It features quick-connect terminals and supports operating voltages of 125VAC and 250VAC with a rated current of 10A at 50/60Hz. The unit operates within a temperature range of -40°C to +100°C and measures 90mm in length. Certified by UL and cUL, it provides high symmetrical attenuation for electromagnetic interference suppression.

Feature Summary

• Single-stage filtering architecture for effective noise reduction
• High symmetrical attenuation performance
• Chassis mount installation style
• Quick connect terminal interface

Applications

• Industrial equipment power conditioning
• Medical device power supplies
• General electronic apparatus EMI suppression

Procurement Notes

Verify the specific voltage rating (125VAC or 250VAC) required for your application against the datasheet specifications. Confirm that the chassis mounting dimensions and quick-connect terminal types match your system design. Ensure compliance with local safety certifications such as UL and cUL before finalizing procurement decisions.

Selection Notes

Select this component when a compact, single-phase solution is needed for moderate current applications up to 10A. Consider the operating temperature range of -40°C to +100°C for environmental suitability. Evaluate the physical size constraints relative to the 90mm length and chassis mounting requirements.

Part Context

This part belongs to Schurter's FMAB series of single-phase power line filters. These components are engineered for general-purpose electromagnetic compatibility in AC power lines. The series offers various current ratings and voltage options to suit different industrial and commercial power supply architectures.

Replacement Considerations

Consult official Schurter documentation for verified substitute part numbers. Cross-referencing requires matching electrical ratings, physical dimensions, and certification status.
