5500.2635.07

Overview

The SCHURTER Inc. 5500.2635.07 is a single-phase, single-stage power line filter designed for chassis mounting. It operates at a rated voltage of 250VAC and supports a continuous current of 10A. The component utilizes quick connect terminals for circuit integration. It is certified by cULus, ENEC, and VDE agencies, indicating compliance with international safety standards. The unit is specifically engineered for medical applications, ensuring reliable electromagnetic compatibility performance in sensitive environments.

Feature Summary

• Single-stage electromagnetic interference filtering architecture
• Chassis mount mechanical configuration
• Medical grade certification compliance

Applications

• Medical equipment power supplies
• Industrial control systems
• Electronic test and measurement devices

Procurement Notes

Verify the specific ordering suffix to confirm terminal type and certification requirements. Confirm chassis mounting dimensions against the mechanical drawing. Ensure the operating environment temperature range aligns with the component specifications. Check for updated regulatory documentation before final design approval.

Selection Notes

Select this model when a single-phase solution is required for 250VAC circuits. The 10A rating suits moderate power loads. Chassis mounting is necessary for rigid installation. Medical application support requires verification of specific biocompatibility or isolation standards if applicable to the end device.

Part Context

This component belongs to the SCHURTER FMAB NEO series of power line filters. The series provides compact EMC solutions for various industrial and medical applications. The 5500 series typically features robust construction suitable for demanding operational environments.

Replacement Considerations

The part number 5500.2634.07 is listed as a related variant within the same product family. Verify electrical ratings and physical dimensions before substitution.
