5500.2636.07

Overview

The SCHURTER Inc. 5500.2636.07 is a single-phase EMC/EMI line filter module designed for chassis mounting. It operates at a rated voltage of 125VAC and 250VAC with a continuous current rating of 12A. The unit functions as a single-stage filter suitable for 50/60Hz applications. It provides electromagnetic interference suppression for electronic equipment requiring clean power input.

Feature Summary

• Single-phase EMI/EMC filtering capability
• Chassis mount construction
• Compact block filter design

Applications

• Industrial control systems
• Medical equipment power supplies
• General purpose electronic devices

Procurement Notes

Verify the exact datasheet specifications before integration, as component variants may exist within the M80 FMAB NEO series. Confirm that the 12A rating and single-stage topology align with your system's noise attenuation requirements. Ensure chassis mounting provisions are available in the enclosure design to accommodate this specific form factor.

Selection Notes

Select this component when a compact, single-phase solution is required for chassis installation. It is appropriate for applications needing 12A capacity at standard mains voltages. Consider the physical dimensions and terminal type compatibility during the mechanical design phase to ensure proper fit and electrical connection within the target assembly.

Part Context

This part belongs to the SCHURTER M80 FMAB NEO series of line filters. These modules are engineered for efficient noise suppression in space-constrained environments. The series offers standardized ratings for common industrial and commercial power distribution needs, providing reliable performance across various global voltage standards.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
