Product Detailed Parameters
- Description：LINE FILTER 125V/250VAC 16A CHAS
- Series：FMAB NEO
- Mfr：SCHURTER Inc.
- Package：Box
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：125V, 250V
- Current：16 A
- Frequency - Operating：50/60Hz
- Applications：Medical
- Approval Agency：cURus, ENEC, VDE
- Operating Temperature：-40°C ~ 100°C
- Mounting Type：Chassis Mount
- Termination Style：Quick Connect
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The SCHURTER Inc. 5500.2637.04 is a single-phase, single-stage power line filter designed for chassis mounting. It features quick connect termination style and supports rated AC voltages of 125VAC and 250VAC with a current rating of 16A. The component operates within a temperature range of -40°C to 100°C. It holds certifications from UL, CSA, VDE, and EN standards, ensuring compliance for international applications.
Feature Summary
- Single-stage EMI filtering configuration for single-phase AC power lines
- Chassis mount design with quick connect termination style
- Certified to UL, CSA, VDE, and EN safety standards
Applications
- Industrial equipment requiring EMI suppression
- Medical devices needing certified power line filtration
- Computer equipment power input stages
Procurement Notes
Verify the specific voltage rating (125VAC or 250VAC) required for your application against the datasheet specifications. Confirm that the quick connect termination style matches your PCB or wiring harness interface. Ensure chassis mounting provisions are available in the final enclosure design to accommodate the filter's physical dimensions and grounding requirements.
Selection Notes
Select this component when a single-stage filter is sufficient for the noise environment. The 16A rating suits moderate power applications. Verify compatibility with both 125VAC and 250VAC systems if dual-voltage operation is needed. Consider the chassis mount form factor if panel integration is preferred over PCB mounting alternatives.
Part Context
This part belongs to Schurter's FMAB series of power line filters. These filters are engineered for general-purpose EMI suppression in AC mains applications. The series offers various current ratings and termination options to fit diverse industrial and commercial power supply architectures.
Replacement Considerations
Check for direct substitutes within the same FMAB series with matching current ratings and termination styles. Verify that any replacement maintains the required UL, CSA, VDE, and EN certifications for the target market.
