Overview

The SCHURTER Inc. 5500.2637.07 is a single-phase EMC/EMI line filter module designed for AC power applications. It features a rated current of 16 A and operates at voltages up to 250 VAC at 50/60 Hz. The component utilizes a single-stage filtering architecture with quick-connect terminals for circuit integration. It is constructed as a compact filter unit suitable for embedding within electronic equipment power entry stages.

Feature Summary

• Single-stage electromagnetic interference suppression
• Quick-connect terminal interface for PCB mounting
• Compact modular design for space-constrained assemblies

Applications

• Single-phase AC power supply input stages
• Electronic equipment requiring EMI noise reduction
• Industrial control systems with sensitive circuitry

Procurement Notes

Verify the specific voltage rating and current capacity against the target application requirements before procurement. Confirm that the quick-connect terminal type matches the available board layout or mating connectors. Ensure compliance with local safety standards such as UL, CSA, and VDE certifications required for the end product market.

Selection Notes

Select this component when a single-phase solution is sufficient for the system's power distribution needs. Consider the 16 A current rating to ensure adequate headroom for peak loads. Evaluate the physical dimensions to confirm fit within the enclosure constraints. Verify that the quick-connect termination style aligns with the manufacturing assembly process.

Part Context

This part belongs to Schurter's family of AC power line filters. These components are engineered to attenuate conducted electromagnetic interference in electrical networks. The series provides standardized solutions for maintaining signal integrity and regulatory compliance in various electronic devices.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
