5500.2642.07

Overview

The SCHURTER 5500.2642.07 is a single-phase, single-stage power line filter designed for chassis mounting. It supports rated AC voltages of 125V and 250V with a current rating of 6A. The component utilizes quick connect termination styles for circuit integration. Operating at standard frequencies of 50/60Hz, this filter provides electromagnetic interference suppression for sensitive electronic equipment within the specified electrical parameters.

Feature Summary

• Single-phase configuration for effective noise reduction in single-line applications
• Chassis mount design facilitates secure installation in industrial enclosures
• Quick connect termination style enables rapid assembly and maintenance

Applications

• Industrial control systems requiring EMI suppression
• Medical equipment power inputs
• General purpose electronic devices

Procurement Notes

Verify the specific voltage rating (125V or 250V) required for your application against the datasheet specifications. Confirm that the 6A current rating meets system demands. Ensure the chassis mount form factor fits the enclosure design. Check for RoHS compliance status if environmental regulations apply to the final product deployment.

Selection Notes

Select this model when a compact, single-stage solution is needed for low-current applications. The quick connect feature simplifies wiring compared to soldered alternatives. Consider the chassis mount requirement early in the mechanical design phase. Verify compatibility with the operating frequency range of 50/60Hz for global deployment scenarios.

Part Context

This component belongs to Schurter's power line filter portfolio, which focuses on electromagnetic compatibility solutions. The 5500 series typically offers robust filtering capabilities for various industrial and commercial applications. Schurter is recognized for producing high-reliability components for power management and protection circuits across multiple sectors.

Replacement Considerations

Ensure any substitute part matches the 6A current rating and single-phase configuration. Verify that the replacement supports both 125V and 250V ratings if dual-voltage operation is necessary. Confirm that the chassis mount style and quick connect terminals are compatible with existing PCB layouts or wiring harnesses.
