5500.2645.07

$64.38

Description：LINE FILTER 125V/250VAC 16A CHAS
Series：FMAB NEO
Mfr：SCHURTER Inc.
Package：Box

SKU:f40e4a9d82d7 Category: Power Line Filter Modules Brand: SCHURTER Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LINE FILTER 125V/250VAC 16A CHAS
Series：FMAB NEO
Mfr：SCHURTER Inc.
Package：Box
Filter Type：Single Phase
Configuration：Single Stage
Voltage - Rated DC：-
Voltage - Rated AC：125V, 250V
Current：16 A
Frequency - Operating：50/60Hz
Applications：Medical
Approval Agency：cURus, ENEC, VDE
Operating Temperature：-40°C ~ 100°C
Mounting Type：Chassis Mount
Termination Style：Quick Connect
Inductance：-
Voltage - Rated AC (Phase to Ground/Neutral)：-
Voltage - Rated AC (Phase to Phase)：-

Download product information

5500.2645.07

Overview

The SCHURTER Inc. 5500.2645.07 is a single-phase EMC/EMI power line filter module designed for chassis mounting. It operates at a rated voltage of 125VAC and 250VAC with a continuous current rating of 16A at 50/60Hz frequencies. The unit provides electromagnetic interference suppression for AC power lines, ensuring compliance with international safety and EMC standards including cURus, ENEC, and VDE certifications.

Feature Summary

Single-phase EMC/EMI filtering capability for AC power applications
Chassis mount design for secure installation in equipment enclosures
Certified to international safety and EMC standards including cURus, ENEC, and VDE

Applications

Industrial control systems requiring EMI suppression
Medical equipment power inputs
Commercial IT infrastructure power distribution

Procurement Notes

Verify the exact part number suffix and certification marks against the official Schurter datasheet before procurement. Confirm that the chassis mounting dimensions and terminal configurations match your enclosure design requirements. Ensure the 16A current rating and 250VAC voltage specification are suitable for your specific circuit application to avoid performance issues or safety hazards.

Selection Notes

Select this component when single-phase EMI filtering is required for 16A circuits operating at 125V or 250VAC. Consider the chassis mounting style and physical footprint constraints during system design. Verify that the certified safety ratings meet the regulatory requirements of the target market, specifically checking for cURus, ENEC, and VDE approvals as documented by the manufacturer.

Part Context

This component belongs to the SCHURTER power line filter module family, which offers various configurations for electromagnetic interference suppression. These filters are engineered to protect sensitive electronic equipment from conducted noise on AC power lines while maintaining compliance with global safety regulations. The series supports diverse industrial and commercial applications requiring reliable power quality management.
