5500.2646.04

Overview

The SCHURTER Inc. 5500.2646.04 is a single-phase, single-stage power line filter designed for chassis mounting. It operates at a rated voltage of 250VAC and supports a continuous current of 20A. The component functions within a frequency range of 50/60Hz and is rated for an operating temperature between -40°C and 100°C. This EMC/EMI filter utilizes quick connect terminals for circuit integration.

Feature Summary

• Single-stage electromagnetic interference suppression
• Chassis mount mechanical configuration
• Quick connect terminal interface

Applications

• Industrial equipment power conditioning
• Medical device power supply filtering
• General electronic apparatus EMI reduction

Procurement Notes

Verify the specific manufacturer part number against official Schurter documentation to confirm electrical ratings and physical dimensions. Ensure compatibility with existing chassis mounting holes and terminal spacing. Confirm RoHS compliance status through current datasheets before finalizing procurement specifications.

Selection Notes

Select this component when a 20A single-phase filter is required for chassis installation. Verify that the 250VAC rating meets system voltage requirements. Consider the -40°C to 100°C operating range for environmental suitability. Ensure quick connect terminals match the wiring harness design.

Part Context

This component belongs to the Schurter FMAB series of power line filters. These modules are engineered for compact integration into various electronic systems requiring reliable noise suppression. The series offers standardized mounting options and consistent performance characteristics across different current ratings.

Replacement Considerations

Consult official Schurter substitution guides for verified alternatives. Cross-reference electrical parameters such as current rating, voltage, and inductance values. Ensure mechanical dimensions and terminal types match the existing design constraints.
