- Description：LINE FILTER 125V/250VAC 20A CHAS
- Series：FMAB NEO
- Mfr：SCHURTER Inc.
- Package：Box
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：125V, 250V
- Current：20 A
- Frequency - Operating：50/60Hz
- Applications：Medical
- Approval Agency：cURus, ENEC, VDE
- Operating Temperature：-40°C ~ 100°C
- Mounting Type：Chassis Mount
- Termination Style：Quick Connect
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The SCHURTER 5500.2646.07 is a single-phase, single-stage power line filter designed for chassis mounting. It supports a continuous current rating of 20A and operates at voltages up to 250VAC (125VAC/250VAC). The component utilizes quick connect termination style for circuit integration. Operating temperature range spans from -40°C to +100°C. It complies with RoHS directives and is classified under power condition sub-categories.
Feature Summary
- Single-stage electromagnetic interference suppression for single-phase AC lines
- Chassis mount mechanical design for secure installation
- Quick connect termination interface for simplified wiring
Applications
- Industrial equipment power input stages
- Medical device power conditioning
- Commercial appliance EMC filtering
Procurement Notes
Verify the complete part number including suffix .07 against official Schurter documentation to ensure correct termination and voltage ratings. Confirm RoHS compliance status through current manufacturer certificates. Check datasheet revisions for any updates to electrical characteristics or mechanical dimensions prior to procurement.
Selection Notes
Select this component when single-phase EMI filtering is required for high-current applications up to 20A. Ensure chassis mounting space accommodates the physical dimensions. Verify that quick connect terminals match existing harness specifications. Confirm operating temperature requirements fall within the -40°C to +100°C range.
Part Context
This component belongs to the Schurter 5500 series of power line filters. The series offers various current ratings and configuration options for single-phase applications. The 5500.2646.07 variant specifically addresses 20A requirements with quick connect termination, fitting into broader industrial and commercial power management systems.
Replacement Considerations
Consult official Schurter substitution guides for verified equivalents. Cross-reference electrical ratings and mechanical footprint before considering alternative manufacturers. No specific substitute part numbers are publicly confirmed in available documentation.
