5500.2650.04

Overview

The SCHURTER 5500.2650.04 is a single-stage power line filter designed for single-phase applications. It supports voltage ratings of 125 VAC and 250 VAC with a current rating of 1 A. The unit utilizes chassis mount installation and features quick-connect terminals. Operating frequencies are specified at 50 Hz and 60 Hz. The component weighs approximately 80 grams and complies with RoHS standards.

Feature Summary

• Single-stage electromagnetic interference suppression
• Chassis mounting configuration
• Quick-connect terminal interface

Applications

• Single-phase electronic equipment protection
• Industrial control panel filtering
• Medical device power input conditioning

Procurement Notes

Verify the specific datasheet revision to confirm compliance certifications such as UL, CSA, or VDE, as these vary by region. Ensure the quick-connect terminal dimensions match the mating connector specifications. Confirm that the 1 A current rating aligns with the maximum load requirements of the target circuit to prevent thermal overload during continuous operation.

Selection Notes

Select this component when a compact, single-stage solution is required for low-current single-phase lines. The chassis mount style necessitates adequate panel space and secure mechanical fastening points. Verify that the 1 A rating provides sufficient margin above the operational current draw. Consider leakage current limits if used in sensitive medical or safety-critical environments requiring strict isolation standards.

Part Context

This part belongs to the FMAB series of power line filters manufactured by SCHURTER. The series offers various current ratings and stage configurations. The 5500.2650.04 specifically addresses low-current applications where minimal footprint and simple installation via chassis mounting are prioritized over multi-stage attenuation capabilities.

Replacement Considerations

Direct substitutes include other SCHURTER FMAB series units with identical 1 A ratings and single-stage topology. Cross-brand replacements must match the 125/250 VAC voltage rating, 1 A current capacity, and chassis mount form factor. Terminal type compatibility is critical when evaluating alternative suppliers.
