5500.2650.07

Overview

The Schurter 5500.2650.07 is a single-phase, single-stage power line filter designed for electromagnetic interference suppression. It supports a maximum current of 1 A and operates at voltages up to 250 V AC across 50 Hz and 60 Hz frequencies. The unit features quick connect terminals and chassis mounting. Key electrical parameters include a leakage current of 500 μA, resistance of 12 mΩ, and power loss of 0.86 W. Physical dimensions are 64 mm in length, 35.5 mm in depth, and 24.8 mm in height.

Feature Summary

• Single-stage filtering architecture for effective noise attenuation
• Quick connect terminal configuration for simplified wiring
• Chassis mounting style for secure installation

Applications

• Electromagnetic compatibility (EMC) protection in electronic equipment
• Power supply input filtering for single-phase devices
• Industrial control systems requiring noise suppression

Procurement Notes

Verify the specific ordering suffix against official Schurter documentation to ensure correct terminal type and certification compliance. Confirm that the 1 A rating and 250 V AC voltage align with your system requirements. Check for any regional regulatory approvals necessary for your target market before finalizing procurement.

Selection Notes

Select this component when a compact, single-stage solution is sufficient for low-current applications. Ensure the quick connect interface matches your PCB or wire harness design. Verify that the 500 μA leakage current meets safety standards for your specific application environment.

Part Context

This part belongs to the FMAB NEO series from Schurter, which focuses on compact power line filters. The series is characterized by its small footprint and suitability for space-constrained designs. It complements other Schurter filtering solutions offering varying current ratings and stage configurations.

Replacement Considerations

Consult official Schurter substitution guides for verified alternatives. Cross-reference current ratings, voltage limits, and physical dimensions to ensure mechanical and electrical compatibility without modifying existing board layouts.
