5500.2652.04

Overview

The SCHURTER 5500.2652.04 is a single-phase power line filter from the FMAB NEO series, rated for 6 A maximum current and 250 V AC operation at 50/60 Hz. Designed for flange mounting with quick-connect terminals, it features a compact chassis-mount footprint measuring 64 mm in length, 35.5 mm in depth, and 24.8 mm in height. The unit exhibits a low resistance value of 12 mΩ and a power loss of 0.86 W under rated conditions. It operates within a temperature range of -40°C to 100°C and maintains a leakage current of 500 μA.

Feature Summary

• Single-stage EMI suppression for single-phase AC circuits
• Flange mount construction for secure panel integration
• Quick-connect terminal interface for simplified wiring

Applications

• Industrial control panels requiring EMI filtering
• Medical equipment power inputs
• Office automation devices

Procurement Notes

Verify the complete part number including suffixes against official Schurter documentation to ensure correct terminal configuration and certification status. Confirm lead times as manufacturing schedules may vary. Ensure compatibility with existing panel cutouts and terminal types before procurement.

Selection Notes

Select this component when a single-phase, 6 A rated filter is required for chassis mounting. Consider the physical dimensions and quick-connect terminal style for PCB or wire harness integration. Verify thermal management requirements given the 0.86 W power loss specification.

Part Context

This component belongs to the FMAB NEO series of power line filters manufactured by Schurter. The series is designed for general industrial and commercial applications requiring reliable EMI suppression in single-phase AC power systems.

Replacement Considerations

Consult official Schurter substitution guides for verified equivalents. Do not assume cross-compatibility with other manufacturers' filters without verifying electrical ratings, mounting dimensions, and terminal configurations.
