Product Detailed Parameters
- Description：LINE FILTER 125V/250VAC 6A CHASS
- Series：FMAB NEO
- Mfr：SCHURTER Inc.
- Package：Box
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：125V, 250V
- Current：6:00 AM
- Frequency - Operating：50/60Hz
- Applications：Medical
- Approval Agency：cURus, ENEC, VDE
- Operating Temperature：-40°C ~ 100°C
- Mounting Type：Chassis Mount
- Termination Style：Quick Connect
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The SCHURTER 5500.2652.07 is a single-phase EMC/EMI power line filter from the FMAB NEO series, rated for 6 A at 250 VAC and 125 VAC with 50/60 Hz operation. It features quick-connect terminals and flange mounting. Key electrical parameters include a maximum leakage current of 500 μA, resistance of 12 mΩ, and power loss of 0.86 W. The unit operates between -40°C and +100°C, with dimensions of 64 mm length, 35.5 mm depth, and 24.8 mm height.
Feature Summary
- Single-stage EMI suppression design
- Quick-connect terminal interface
- Flange mounting configuration
Applications
- Industrial equipment power input
- Medical device power supplies
- Consumer electronics filtering
Procurement Notes
Verify the specific ordering suffix to confirm terminal type and voltage rating. Confirm flange mounting hole patterns match the application chassis. Check for RoHS compliance status in the latest datasheet. Ensure the 6 A continuous current rating meets system requirements under all operating temperatures.
Selection Notes
Select this component for applications requiring compact single-phase filtering with quick-connect convenience. Verify that the 500 μA leakage current limit complies with safety standards for the intended medical or industrial environment. Ensure the operating temperature range covers the full system thermal profile.
Part Context
This part belongs to the Schurter FMAB NEO series of power line filters. The series offers various current ratings and terminal options. The 5500.2652.07 specifically denotes the 6 A variant with quick-connect terminals and flange mount capability within this product family.
Replacement Considerations
Check Schurter documentation for direct replacements within the FMAB NEO series. Verify compatibility of mounting holes and terminal spacing when substituting with other single-phase filters.
