5500.2656.04

$23.16

Description：LINE FILTER 125V/250VAC 20A CHAS
Series：FMAB NEO
Mfr：SCHURTER Inc.
Package：Box

SKU:64d29dd43d05 Category: Power Line Filter Modules Brand: SCHURTER Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LINE FILTER 125V/250VAC 20A CHAS
Series：FMAB NEO
Mfr：SCHURTER Inc.
Package：Box
Filter Type：Single Phase
Configuration：Single Stage
Voltage - Rated DC：-
Voltage - Rated AC：125V, 250V
Current：20 A
Frequency - Operating：50/60Hz
Applications：Medical
Approval Agency：cURus, ENEC, VDE
Operating Temperature：-40°C ~ 100°C
Mounting Type：Chassis Mount
Termination Style：Quick Connect
Inductance：-
Voltage - Rated AC (Phase to Ground/Neutral)：-
Voltage - Rated AC (Phase to Phase)：-

Download product information

5500.2656.04

Overview

The SCHURTER Inc. 5500.2656.04 is a single-phase, single-stage power line filter designed for chassis mounting. It operates at a voltage rating of 125/250VAC and supports a current capacity of 20A at 50/60Hz frequencies. The component utilizes quick connect terminals for circuit integration. It is RoHS3 compliant and classified under the Power Condition sub-category within Schurter's product portfolio.

Feature Summary

Single-stage electromagnetic interference (EMI) filtering architecture
Chassis mount installation style with quick connect terminals
RoHS3 compliance for environmental standards

Applications

Industrial equipment power conditioning
Medical device power supply input stages
General electronic apparatus EMI suppression

Procurement Notes

Verify the specific datasheet version to confirm terminal configuration and attenuation curves. Ensure the 20A current rating aligns with system requirements. Check for RoHS3 compliance documentation if required by regulatory standards. Confirm chassis mounting dimensions against enclosure specifications before procurement.

Selection Notes

Select this component for applications requiring single-phase EMI filtration in compact chassis-mounted designs. The 20A rating suits moderate power loads. Verify that the quick connect interface matches existing wiring harnesses. Consider thermal management capabilities relative to the expected operating environment and continuous load conditions.

Part Context

This part belongs to Schurter's 5500 series of power line filters. The series offers various current ratings and stage configurations. The 5500.2656.04 specifically addresses single-phase needs with a 20A capacity. It complements other Schurter components like the 5500.2640.04, which offers lower current ratings.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Consult official Schurter documentation for potential cross-references or updated model equivalents.
