5500.2656.07

$24.64

Description：LINE FILTER 125V/250VAC 20A CHAS
Series：FMAB NEO
Mfr：SCHURTER Inc.
Package：Box

SKU:ad0cc90a0f9f Category: Power Line Filter Modules Brand: SCHURTER Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LINE FILTER 125V/250VAC 20A CHAS
Series：FMAB NEO
Mfr：SCHURTER Inc.
Package：Box
Filter Type：Single Phase
Configuration：Single Stage
Voltage - Rated DC：-
Voltage - Rated AC：125V, 250V
Current：20 A
Frequency - Operating：50/60Hz
Applications：Medical
Approval Agency：cURus, ENEC, VDE
Operating Temperature：-40°C ~ 100°C
Mounting Type：Chassis Mount
Termination Style：Quick Connect
Inductance：-
Voltage - Rated AC (Phase to Ground/Neutral)：-
Voltage - Rated AC (Phase to Phase)：-

Download product information

5500.2656.07

Overview

The SCHURTER Inc. 5500.2656.07 is a single-phase EMC/EMI line filter designed for chassis mounting. It operates at a rated voltage of 125/250VAC and supports a continuous current of 20A at 50/60Hz. The component utilizes a quick connect terminal interface for circuit integration. It complies with RoHS3 standards and carries an EAR99 classification.

Feature Summary

Single-stage electromagnetic interference suppression
Chassis-mountable mechanical design
Quick-connect terminal interface

Applications

Industrial equipment power distribution
Medical device power supplies
Computer equipment filtering

Procurement Notes

Verify the exact datasheet version before implementation, as specifications may vary by revision. Confirm that the quick-connect terminals match your PCB or wire harness requirements. Ensure the chassis mounting holes align with your enclosure design. Check for any specific regulatory certifications required for your target market.

Selection Notes

Select this component when a single-phase, 20A rated EMI filter is required for chassis installation. The quick-connect interface simplifies assembly compared to soldered alternatives. Verify that the 125/250VAC rating meets your system's voltage requirements. Consider the physical dimensions for chassis cutout compatibility.

Part Context

This part belongs to SCHURTER's line filter portfolio, which includes various configurations for different current ratings and mounting styles. The 5500 series typically offers robust noise attenuation for sensitive electronic loads. It is distinct from cable assemblies and fuses within the same manufacturer catalog.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult SCHURTER technical support for equivalent components if this part is discontinued or unavailable.
