5975006507F

Overview

The Dialight 5975006507F is a red surface-mount LED indicator from the 597 series, designed for discrete indication applications. It features a rectangular lens with a flat top and operates at a forward voltage of 2V with a test current of 20mA. The component emits light at a wavelength of 630nm and provides an intensity of 120mcd. Packaged in an 0805 (2012 metric) case measuring 2.00mm x 1.25mm x 0.93mm max, it complies with RoHS3 standards.

Feature Summary

• Rectangular lens style with a flat top design
• Standard configuration for discrete indication
• Compliant with RoHS3 environmental standards

Applications

• Discrete electronic indication
• Surface mount panel indicators
• General status signaling in electronic assemblies

Procurement Notes

Verify component availability as this part may be discontinued or subject to supply constraints. Confirm RoHS3 compliance and MSL level 3 handling requirements during storage and assembly. Cross-reference manufacturer datasheets for final electrical characteristics before integration into designs.

Selection Notes

Select this component for applications requiring a standard red SMD indicator with specific dimensional constraints. Ensure circuit design accommodates the 2V forward voltage and 20mA test current. Consider the 120mcd intensity for visibility requirements in the target environment.

Part Context

This component belongs to the Dialight 597 series of single-color LEDs. It utilizes a 0805 surface-mount package suitable for automated placement. The red color corresponds to a 630nm wavelength, providing clear visual feedback in industrial and commercial electronics.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
