5SGXMA3H2F35C2WN

Overview

The Altera 5SGXMA3H2F35C2WN is a Stratix V GX Field Programmable Gate Array (FPGA) belonging to the 5SGXMA3 device family. It features 340,000 logic elements and 128,300 Adaptive Logic Modules (ALMs). The device integrates 19 Mbit of embedded memory and provides 600 I/Os within an FCBGA-1152 package. It supports data rates up to 14.1 Gb/s via its transceiver architecture. The core operating voltage is specified at 850 mV, with a standard commercial temperature range of 0°C to +70°C.

Feature Summary

• Stratix V GX architecture optimized for high-speed serial communications
• Integrated hard processor system support capabilities
• Advanced power management techniques for thermal efficiency

Applications

• High-speed networking infrastructure equipment
• Telecommunications baseband processing units
• Industrial automation control systems

Procurement Notes

Verify component authenticity through authorized channels due to potential availability constraints. Confirm moisture sensitivity level handling requirements prior to assembly. Ensure compatibility with existing PCB footprint designs. Validate supply chain documentation against official manufacturer records.

Selection Notes

Compare logic density and transceiver counts against alternative Stratix V variants. Assess power consumption profiles relative to specific application loads. Verify pinout compatibility if replacing legacy components. Evaluate thermal dissipation requirements for the target enclosure design.

Part Context

This component belongs to the Altera Stratix V GX series, designed for demanding serial communication applications. The 5SGXMA3 sub-family offers a balance of logic resources and high-speed I/O capabilities. It serves as a key solution for bandwidth-intensive digital signal processing tasks in enterprise environments.

Replacement Considerations

Direct substitutes include the 5SGXMA3H2F35C2LG and 5SGXMA3H2F35C2LN. These variants share identical functional specifications but may differ in packaging suffixes or regional certification markings. Verify mechanical dimensions before integration.
