5VB1

Overview

The TE Connectivity Corcom Filters 5VB1 is a single-phase EMC/EMI line filter module designed for commercial and medical applications. It features a rated current of 5 A at 250 VAC (50/60 Hz) with a leakage current of 4 mA at 120 VAC and 7 mA at 250 VAC. The component utilizes quick connect terminals measuring 0.187 inches (4.7 mm) for termination. It provides high impedance filtering suitable for low current loads while meeting strict leakage current requirements.

Feature Summary

• Provides effective attenuation of unwanted electrical noise within the 50Hz/60Hz frequency range
• Designed to meet low leakage current requirements specified for portable equipment
• Suitable for high impedance loads operating at low current levels

Applications

• Portable equipment requiring strict leakage current compliance
• High impedance load circuits
• General purpose RFI filtering in commercial devices

Procurement Notes

Verify the specific terminal configuration matches the 0.187-inch quick connect requirement before integration. Confirm that the 5A current rating and 250VAC voltage rating align with the target circuit design. Ensure the leakage current specifications of 4mA at 120VAC and 7mA at 250VAC satisfy the safety standards of the final application. Check for RoHS3 compliance status if required by the manufacturing process.

Selection Notes

Select this model when low leakage current is critical for portable equipment safety certification. It is appropriate for applications involving high impedance loads where standard filters might not perform optimally. Consider the 5A current rating as the maximum limit for continuous operation. Ensure the chassis or panel mounting method accommodates the module form factor.

Part Context

This component belongs to the Corcom Series B RFI Filter family from TE Connectivity. It is categorized as a power line filter module intended for single-phase AC power lines. The series is known for providing EMI/RFI suppression in various electronic devices, balancing performance with compact physical dimensions.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
