6035S42000BMDAFBCCE-CT

Crystals Overview

The HKC 6035S42000BMDAFBCCE-CT is a surface-mount MHz crystal oscillator designed for precision timing applications. It operates at a fundamental frequency of 20 MHz with a frequency tolerance of ±10ppm and stability of ±15ppm over the industrial temperature range of -40°C to +85°C. The component utilizes a 12pF load capacitance and features a series resistance of 30 Ohms. Packaged in a compact 4-SMD, no-lead form factor with a maximum height of 1.50mm, it supports RoHS3 compliance for environmentally conscious manufacturing.

Crystals Feature Summary

• Provides stable 20 MHz oscillation within tight ppm tolerances
• Operates reliably across extended industrial temperature ranges
• Supports automated surface-mount assembly processes

Crystals Applications

• Microcontroller clock sources
• Communication interface timing
• Digital signal processing circuits

Crystals Procurement Notes

Verify the specific suffix against manufacturer documentation to confirm exact electrical characteristics and packaging configuration. Ensure compatibility with existing PCB footprint and reflow profiles. Cross-reference part numbers carefully as minor variations may exist between distributors. Confirm RoHS3 compliance status if required by regulatory standards. Validate supplier authenticity through authorized channels.

Crystals Selection Notes

Select this component when precise 20 MHz timing is required in space-constrained designs. Consider the 12pF load capacitance requirement for circuit matching. Evaluate the 30 Ohm series resistance impact on drive level. Assess thermal performance within the specified -40°C to +85°C range. Compare physical dimensions against available board real estate constraints.

Crystals Part Context

This crystal belongs to HKC's standard MHz crystal lineup, focusing on reliable frequency generation for digital electronics. HKC manufactures semiconductor display panels but also supplies passive components like crystals for broader electronic applications. This specific model represents a common industry-standard frequency point suitable for general-purpose timing needs.

Crystals Replacement Considerations

Consult official substitution lists for direct equivalents. Verify pinout compatibility and electrical parameter alignment before replacement. Check mechanical dimension tolerances to ensure fit within existing assemblies.
