60DCF6

Overview

The TE Connectivity Corcom 60DCF6 is a single-phase EMI filter designed for AC power line applications. It features a C2 package configuration with screw terminals for secure mounting. The unit provides common mode and differential mode attenuation to suppress electromagnetic interference in sensitive electronic equipment. Rated for 6A continuous current at 250VAC, it meets safety standards including UL and CSA certifications. The filter integrates capacitors and an inductor within a compact metal housing to ensure reliable noise reduction in industrial and commercial environments.

Feature Summary

• Provides effective suppression of conducted electromagnetic interference on AC power lines
• Utilizes a robust metal enclosure for enhanced shielding and mechanical durability
• Designed with screw terminal connections for secure and reliable electrical integration

Applications

• Industrial control systems requiring noise immunity
• Medical equipment power supplies
• Commercial office automation devices
• Test and measurement instrumentation

Procurement Notes

Verify the specific ordering suffix against the manufacturer's latest datasheet to confirm terminal type, voltage rating, and certification marks. Ensure the selected variant matches the required installation orientation and mounting hole pattern. Cross-reference the part number with official TE Connectivity documentation to validate compliance with current regional safety regulations before procurement.

Selection Notes

Select this component based on the system's maximum operating current and voltage requirements exceeding 6A and 250VAC respectively. Consider the physical dimensions of the C2 package to ensure compatibility with existing chassis or panel cutouts. Evaluate the required attenuation levels at specific frequency ranges to confirm adequate performance for the target application's noise profile.

Part Context

This model belongs to the Corcom series of power line filters manufactured by TE Connectivity. The series offers various configurations tailored for different current ratings and form factors. The 60DCF6 specifically addresses single-phase applications where moderate current capacity and standard attenuation characteristics are sufficient for general-purpose noise suppression tasks.

Replacement Considerations

Consult official TE Connectivity substitution guides for direct equivalents. Verify that any alternative part matches the pinout, mounting style, and electrical specifications exactly. Do not assume interchangeability without confirming technical data sheets from both manufacturers.
