6100BP14A1955001T

$1.03

Description：RF FILTER BAND PASS 6.1GHZ 0603
Series：-
Mfr：Johanson Technology Inc.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:e513452df32f Category: RF Filters Brand: Johanson Technology Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：RF FILTER BAND PASS 6.1GHZ 0603
Series：-
Mfr：Johanson Technology Inc.
Package：Tape & Reel (TR),Cut Tape (CT)
Frequency：6.1GHz Center
Bandwidth：1.955GHz
Filter Type：Band Pass
Ripple：-
Insertion Loss：0.9dB
Mounting Type：Surface Mount
Package / Case：0603 (1608 Metric), 3 PC Pad
Size / Dimension：0.063" L x 0.031" W (1.60mm x 0.80mm)
Height (Max)：0.026" (0.65mm)

Download product information

6100BP14A1955001T

Overview

The 6100BP14A1955001T is a bandpass filter manufactured by Johanson Technology, designed for signal conditioning applications. It operates within a frequency range of 5.17 GHz to 7.125 GHz, centered around a nominal frequency of 6.1 GHz. The component utilizes an EIA 0603 (1608 metric) surface-mount package with SMD/SMT termination types. It features a 50-ohm impedance and is rated for operation between -40°C and +85°C. This device is part of the BP series and is supplied in tape and reel packaging.

Feature Summary

Provides bandpass filtering characteristics for RF signal conditioning
Engineered for low insertion loss and high attenuation outside the passband
Compatible with standard surface-mount assembly processes

Applications

Wireless communication systems operating in the 5.17–7.125 GHz range
RF front-end modules requiring signal isolation
Test and measurement equipment filters

Procurement Notes

Verify the complete part number including the trailing 'T' for tape-and-reel configuration against official Johanson Technology documentation. Confirm RoHS compliance status through current datasheets. Ensure compatibility with 0603 footprint dimensions during PCB layout review. Cross-reference legacy identifiers if replacing older versions.

Selection Notes

Select this component when a 6.1 GHz center frequency with a wide bandwidth is required. The 0603 package suits space-constrained designs. Verify that the 50-ohm system impedance matches the circuit requirements. Consider thermal ratings up to 85°C for operational environments.

Part Context

This part belongs to Johanson Technology's BP series of bandpass filters. These components are integrated passive devices intended for RF applications. The manufacturer specializes in miniaturized RF solutions for mobile and wireless infrastructure markets.

Replacement Considerations

Legacy part number 6100BP14A1955 may be referenced as an equivalent identifier. Verify electrical specifications and physical dimensions before substitution.
