6609020-1

Overview

The TE Connectivity Corcom Filters model 6609020-1 is a single-phase power line filter designed for chassis mounting. It features a rated current of 20 A and a voltage rating of 250 VAC. The component utilizes an inductance value of 516 µH to provide electromagnetic interference suppression. The unit employs a screw terminal connection style for secure electrical interfacing. This filter belongs to the B series, which is engineered for high impedance loads at low current levels.

Feature Summary

• Engineered for wide band RFI suppression
• Designed for high impedance loads
• Suitable for low current applications

Applications

• General purpose power line filtering
• Equipment requiring wide band RFI suppression
• Chassis mounted electronic assemblies

Procurement Notes

Verify the specific datasheet version before procurement, as product attributes may vary between revisions. Confirm that the chassis mounting requirements align with your enclosure design. Ensure the screw terminal interface matches your wiring harness specifications. Check for any RoHS compliance updates relevant to your region's regulations prior to finalizing the order.

Selection Notes

Select this component when a single-phase filter with a 20 A rating is required. The 516 µH inductance provides specific attenuation characteristics suitable for general EMI reduction. Verify that the chassis mount form factor fits within the available space. Consider the screw termination method if faston connectors are not preferred for the 20 A load.

Part Context

This part belongs to the TE Connectivity Corcom B Series of RFI filters. The series is characterized by its focus on high impedance loads and wide band suppression capabilities. It serves as a solution for reducing radio frequency interference in power lines where standard filtering may be insufficient for specific noise profiles.

Replacement Considerations

Public confirmed substitute part numbers were not found in the provided documentation.
