Overview

The TE Connectivity Corcom Filters model 6609031-4 is a single-phase EMC/EMI power line filter designed for chassis mounting. It features wire lead termination for both input and output connections. The component operates at a rated voltage of 250 VAC and supports a continuous current of 2 A. Designed for standard utility frequencies, it functions effectively at 50 Hz and 60 Hz. This two-stage filter utilizes internal components, including a 203µF capacitor and a 495µH inductor, to attenuate radio frequency interference.

Feature Summary

• Two-stage filtering configuration for enhanced noise suppression
• Chassis mount installation style with wire lead terminations
• Internal integration of high-capacitance and high-inductance components

Applications

• General purpose EMI/RFI suppression in electronic equipment
• Power line conditioning for AC mains inputs
• Industrial control systems requiring noise reduction

Procurement Notes

Verify the specific part number 6609031-4 against official TE Connectivity documentation to confirm current availability and manufacturing status. Ensure that the required 2A current rating and 250VAC voltage specifications align with the target application's electrical requirements. Confirm that wire lead termination is compatible with the system wiring design before procurement.

Selection Notes

Select this component when a two-stage filtering solution is required for single-phase AC applications operating at 50/60Hz. The chassis mount form factor and wire lead outputs dictate the mechanical integration strategy. Consider the internal component values for specific attenuation characteristics compared to other series within the Corcom lineup.

Part Context

This component belongs to the Corcom R series of single-phase filters from TE Connectivity. It is internally identified as 1-6609031-4. The series is characterized by general-purpose RFI suppression capabilities suitable for commercial and industrial environments where chassis mounting is preferred over panel mount connectors.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material.
